Flutter Plugin for a Attractive Staggered gird view, flutter_staggered_grid_view

A plugin in flutter (flutter plugin) is a wrapper for native code such as Android (Kotlin or Java) and iOS (iOS) (swift or objective c). For the plugin, we’ll need to create Android and iOS-specific code. For Android, we can use Kotlin or Java, and for iOS, we can use Swift or Objective-C.

flutter_staggered_grid_view

Provides a collection of Flutter grids layouts.

Getting started

In the pubspec.yaml of your flutter project, add the following dependency:

dependencies:
  ...
  flutter_staggered_grid_view: <latest_version>

In your library add the following import:

import 'package:flutter_staggered_grid_view/flutter_staggered_grid_view.dart';

For help getting started with Flutter, view the online documentation.

Layouts

This package contains various grid layouts. In the following section, you’ll discover each one of them. The explanation of the layout will always considered a top-to-bottom and left-to-right directions to simplify the description. However it is possible to change these directions in the code.

Staggered

Staggered Grid Layout

This layout is intended for a small number of items. I didn’t find, for the moment, a performant algorithm which would work in a Sliver context, that’s why this is not a GridView and therefore there are no SliverStaggeredGrid.

Grid properties

  • Evenly divided in n columns
  • Small number of items
  • Not scrollable

Tile properties

  • Must occupy 1 to n columns

Placement algorithm

  • Top-most and then left-most

Example

Below you’ll find the code to create this grid layout:

Staggered example
StaggeredGrid.count(
  crossAxisCount: 4,
  mainAxisSpacing: 4,
  crossAxisSpacing: 4,
  children: const [
    StaggeredGridTile.count(
      crossAxisCellCount: 2,
      mainAxisCellCount: 2,
      child: Tile(index: 0),
    ),
    StaggeredGridTile.count(
      crossAxisCellCount: 2,
      mainAxisCellCount: 1,
      child: Tile(index: 1),
    ),
    StaggeredGridTile.count(
      crossAxisCellCount: 1,
      mainAxisCellCount: 1,
      child: Tile(index: 2),
    ),
    StaggeredGridTile.count(
      crossAxisCellCount: 1,
      mainAxisCellCount: 1,
      child: Tile(index: 3),
    ),
    StaggeredGridTile.count(
      crossAxisCellCount: 4,
      mainAxisCellCount: 2,
      child: Tile(index: 4),
    ),
  ],
);

Masonry

Masonry Grid Layout

This layout facilitates the browsing of uncropped peer content. Container heights are sized based on the widget size.

This is a complete separate grid and not a SliverGridDelegate for performance reasons. The SliverGrid is great but it needs to have a layout which does not depends on the size of its children. Otherwise we have to compute the size to all children before the end of the cache, which is really not performant for a masonry layout.

Grid properties

  • Evenly divided in n columns

Tile properties

  • Must occupy 1 column only

Placement algorithm

  • Top-most and then left-most

Example

Below you’ll find the code to create this grid layout:

Masonry example
MasonryGridView.count(
  crossAxisCount: 4,
  mainAxisSpacing: 4,
  crossAxisSpacing: 4,
  itemBuilder: (context, index) {
    return Tile(
      index: index,
      extent: (index % 5 + 1) * 100,
    );
  },
);

Quilted

Quilted Grid Layout

This layout emphasizes certain items over others in a collection. It creates hierarchy using varied container sizes and ratios.

This is a specific delegate for the built-in GridView (or SliverGrid) widget. That’s why the example below will create such a layout with a GridView.

Grid properties

  • Evenly divided in n columns
  • The height of each row is equal to the width of each column
  • A pattern defines the size of the tiles and different mode of repetition are possible

Tile properties

  • Must occupy 1 to n columns
  • Must occupy 1 or more entire rows

Placement algorithm

  • Top-most and then left-most

Example

Below you’ll find the code to create this grid layout:

Quilted example
GridView.custom(
  gridDelegate: SliverQuiltedGridDelegate(
    crossAxisCount: 4,
    mainAxisSpacing: 4,
    crossAxisSpacing: 4,
    repeatPattern: QuiltedGridRepeatPattern.inverted,
    pattern: [
      QuiltedGridTile(2, 2),
      QuiltedGridTile(1, 1),
      QuiltedGridTile(1, 1),
      QuiltedGridTile(1, 2),
    ],
  ),
  childrenDelegate: SliverChildBuilderDelegate(
    (context, index) => Tile(index: index),
  ),
);

Woven

Woven Grid Layout

This layout facilitates the browsing of peer content. The items are displayed in containers of varying ratios to create a rhythmic layout.

This is a specific delegate for the built-in GridView (or SliverGrid) widget. That’s why the example below will create such a layout with a GridView.

Grid properties

  • Evenly divided in n columns
  • The height the rows is the maximum height of the tiles
  • A pattern defines the size of the tiles
  • The size of the tiles follows the pattern in a ‘z’ sequence.

Tile properties

  • The height is defined by an aspectRatio (width/height)
  • The width is defined by a crossAxisRatio (width/column’s width) between 0 (exclusive) and 1 (inclusive)
  • Each tile can define how it is aligned within the available space

Placement algorithm

  • Top-most and then left-most

Example

Below you’ll find the code to create this grid layout:

Woven example
GridView.custom(
  gridDelegate: SliverWovenGridDelegate.count(
    crossAxisCount: 2,
    mainAxisSpacing: 8,
    crossAxisSpacing: 8,
    pattern: [
      WovenGridTile(1),
      WovenGridTile(
        5 / 7,
        crossAxisRatio: 0.9,
        alignment: AlignmentDirectional.centerEnd,
      ),
    ],
  ),
  childrenDelegate: SliverChildBuilderDelegate(
    (context, index) => Tile(index: index),
  ),
);

Staired

Staired Grid Layout

This layout uses alternating container sizes and ratios to create a rhythmic effect. It’s another kind of woven grid layout.

This is a specific delegate for the built-in GridView (or SliverGrid) widget. That’s why the example below will create such a layout with a GridView.

Grid properties

  • A pattern defines the size of the tiles
  • Each tile is shifted from the previous one by a margin in both axis
  • The placement follows a ‘z’ sequence

Tile properties

  • The height is defined by an aspectRatio (width/height)
  • The width is defined by a crossAxisRatio (width/available horizontal space) between 0 (exclusive) and 1 (inclusive)

Placement algorithm

  • In a ‘z’ sequence

Example

Below you’ll find the code to create this grid layout:

Staired example
GridView.custom(
  gridDelegate: SliverStairedGridDelegate(
    crossAxisSpacing: 48,
    mainAxisSpacing: 24,
    startCrossAxisDirectionReversed: true,
    pattern: [
      StairedGridTile(0.5, 1),
      StairedGridTile(0.5, 3 / 4),
      StairedGridTile(1.0, 10 / 4),
    ],
  ),
  childrenDelegate: SliverChildBuilderDelegate(
    (context, index) => Tile(index: index),
  ),
);

GitHub

Source Code: Flutter Plugin for a Attractive Staggered gird view, flutter_staggered_grid_view.
